Integrated PC Box – IEC-3714

Download the data sheet Integrated PC Box – IEC-3714

Compact Digital Player with Intel® Core™ Ultra Processor

ARBOR’s IEC-3714 is a compact, high-performance embedded PC designed for modern edge AI and digital signage applications.

Powered by the Intel® Core™ Ultra 5-125H (Meteor Lake) processor and integrated with Intel® Arc™ graphics, it delivers 4K media playback, AI acceleration , and power efficiency, all in a fanless, ultra-compact design.

• Powered by Intel® Core™ Ultra 5-125H (Meteor Lake) processor

• Integrated Intel® Arc™ graphics with support for 4K displays

• Wide-range power input: 12–24V DC for greater integration flexibility

• Support for up to 4 displays: 2 × HDMI 2.1 and 2 × DisplayPort via USB-C

Features

• Intel® Core™ Ultra 5-125H processor with AI hybrid engine (CPU/GPU/NPU)

• Intel® Arc™ Graphics, supports up to 4K on 4 independent displays

• Outputs: 2 × HDMI 2.1, 2 × DP 2.1 / DP 1.4a via USB-C

• Up to 96GB DDR5 SO-DIMM (2 slots)

• Dual M.2 PCIe Gen4 for NVMe storage

• 4 × USB 3.2 Type-A and 2 × USB-C

• 1 × 2.5 GbE LAN (Intel® I226LM)

• Power input: 12–24 V DC

• Fanless design with SECC housing

Advantages

• Digital signage ready: smooth 4K video playback and multi-screen support

• AI Performance: Up to 34 TOPS for edge inference and intelligent content delivery

• Flexible connectivity: dual M.2 storage, USB 3.2, and high-speed LAN

• Compact and efficient – ideal for installations with limited space

• Fanless reliability: quiet and stable operation between 0°C and 50°C

• Industrial durability – certified for shock, vibration and 24/7 continuous operation
